GstarCAD Standard


The most affordable CAD software

GstarCAD Standard is one of the most functional solutions for universal 2D drawing on the market. It is considered the best “cost-effective” alternative to AutoCAD LT. With the GstarCAD Standard version, you have unlimited possibilities for 2D CAD drawing in accordance with international regulations and your own standards (line types, hatches, dimensions, templates, etc.). More and more former users of CAD programs, such as AutoCAD LT, are opting for the GstarCAD Standard.

GstarCAD was created to remind you as much as possible of AutoCAD (commands, syntax, palettes, toolbars). However, the goal is that the existing AutoCAD user does not notice large differences between the two programs and consequently does not invest time and money in learning the new CAD program.

Features

Main features

GstarCAD Standard

Precise drawing

By catching the important points, entering coordinates with the keyboard, controlling the cursor position using grid snap or object snap tracks, you can create precise technical drawings quickly, easily and without errors.

GstarCAD Standard

Immediate response

When drawing, modeling or making changes in drafts, you will receive immediate feedback from the program. If you move the cursor, you will see the desired result before confirming or exiting the command.

GstarCAD Standard

Associative dimensions

Annotate dimensions and shapes based on the dimension (linear, aligned, radial, angle, coordinates, arc length, etc.). If you change the design, the dimensions adjust automatically.

GstarCAD Standard

Binding references

Underlay a drawing via an external DWG, DWF, DGN, PDF or raster image. After calibrating the insertion point and size, you can also adjust the transparency. Then continue drawing and dimensioning.

GstarCAD Standard

Faster changes

Create different variants. Functions for copying, stretching or mirroring individually selected objects, through window selection or cross selection make it very easy.

GstarCAD Standard

3D design

GstarCAD is mainly 2D. However you can also creates remarkable 3D designs. It is a “bonus” for the more sophisticated 2D functionality of the Professional version.

GstarCAD Standard

3D modeling

Create 3D models with combination of solids. By joining, subtracting, and intersecting materials, you can get new shapes. The solid analysis provides information about the center of gravity, volume, or moment of inertia.

GstarCAD Standard

3D orbit

Interactive display of models and the ability to set different visual representations (wireframe, realistic,…) gives you control over the 3D design. It can also serve as a tool for presentations

More features

GstarCAD Standard

Dynamic input

You no longer have to constantly check the command line. Concentrate on the cursor area also when typing on the keyboard. The AutoComplete function also provides you with a list of suitable commands.

GstarCAD Standard

“Magnifier” tool

Ideal function for working with large and densely drawn drawings. You no longer need to zoom in and drag the drawing all over the screen to draw a line from point A to point B.

GstarCAD Standard

User interface

Customize the appearance and content of the menu, group commands in the tabs, drop-down list, toolbar. Create the whole working sets for different types of tasks.

GstarCAD Standard

Workspace

Use the modern ribbon interface (related commands clearly summarized in tabs and groups) but if you are more familiar with older AutoCAD version then switch to GstarCAD “Classic”.

GstarCAD Standard

Integrated API

Are you developing an application for AutoCAD? With an API integrated in GstarCAD (LISP, VBA, .NET, GRX – similar to ARX / AutoCAD Runtime eXtension for applications written in C or C ++), your migration will not be difficult.

GstarCAD Standard

Layer manager

It’s like drawing with tracing paper. Draw on individual layers for each industry in a single construction project. Your drawings will be clear, organized and easy to read.

GstarCAD Standard

DWG format

Open drawings directly from colleagues who designed AutoCAD or AutoCAD LT. Complete your part in GstarCAD. Save the drawing and send it back. No import or export. Pure teamwork.

GstarCAD Standard

Norms and standards

Create DWT drawing templates with the required plot style tables, dimension style, line types, hatch patterns, scales, and title blocks. Save time with every new drawing.

News and improvements

GstarCAD 2022

GstarCAD Standard

Improvement in plotting (PLOT)

In GstarCAD 2022 there has been a significant improvement in the area of ​​plotting to PDF format, plotting with transparency, plotting raster images and the function of shaded plotting with the “Hidden” option. The result is therefore much more precise.

GstarCAD Standard

Fixed the raster engine

An updated raster engine has been integrated into GstarCAD 2022, which supports more image formats and even images with 1 billion pixels can now be inserted, illustrated, supplemented and plotted correctly.

GstarCAD Standard

Improvement of the dimensioning tools

GstarCAD 2022 version also offers improved commands DIMREASSOCIATE, DIMREGEN, DIMCENTER, a new option to …. As well as the DIMLAYER command, with the help of which dimensions will be clearer and more precise.

GstarCAD Standard

ACET interface

GstarCAD 2022 already supports 351 ACET (Autocad Express Tools) interfaces. One can now use many more tools and plugins developed within these interfaces.

GstarCAD Standard

Multiline repair

The GstarCAD 2022 version allows easy shortening or lengthening of the multi-line with different objects, lines, polylines, circles, arcs, ellipses, splines, etc.

GstarCAD Standard

Additional

  • Layer tools fix…
  • SDI (Single Document Interface) mode available…
  • Fixing the tools for groups…
  • Improved CHANGEBASE command and more…
MORE INFO

GstarCAD 2021

GstarCAD 2020

GstarCAD 2019

GstarCAD Standard

Redefine the block

Now the Design Center offers a quick way to update block instances. If you redefine a block, you can overwrite any block instance without changing the block name, while maintaining the original block position. If you just copy a newer version of a block into your active drawing, the block is not updated, but the active drawing’s block definition. When a block is redefined it is not necessary to delete, clean or copy.

GstarCAD Standard

Spell check

Mtext now supports spell checking. You can determine whether the spell check should be activated or not. If you enter the wrong word, a red line will appear under the text. You can also easily correct a word by choosing an alternative word from the list of suggestions or by typing a word in the Suggestions box.

GstarCAD Standard

Workspace

The new WORKSPACE command creates, edits and saves workspaces and sets a workspace as the current workspace. You can adapt the ribbon or classic workspace to the requirements of the interface environment.

GstarCAD Standard

Change of selection

With the new SELECTIONCYCLING system variable, you can select overlapping or matching objects in the current drawing as well as set additional options for selecting objects.

GstarCAD Standard

Path entry for drawing comparison

In the command line, after running the Drawing Compare (CMP) command, you can conveniently enter the old, new, and compared drawing file path.

GstarCAD Standard

Settings for hidden messages

In the Options dialog box, on the “User Settings” tab, there is a new option “Settings for hidden messages”, which controls the display of previously hidden messages. After a message has been hidden, it can be viewed and reactivated.

GstarCAD Standard

MOVEBAK

The new MOVEBAK system variable changes the destination folder for drawing backup files (BAK). If you specify a folder, the BAK file of the drawing is also saved in this folder each time it is saved.

GstarCAD Standard

Import layouts as plans

You can now “import” additional drawing layouts into your sheet set file using Sheet Set Manager.

GstarCAD Standard

System variables related to hatching

Some system variables related to hatching have been implemented: HPANNOTATIVE, HPISLANDDETECTION, HPMAXAREAS, HPORIGINSTOREASDEFAULT, HPQUICKPREVTIMEOUT, HPLASTPATTERN, HPLAYER, HPLINETYPE, HPPICKMODE and HPRELATIVEPS.

GstarCAD Standard

Right click + drag method

With the right click + drag method, you can select an object, then hold down the right mouse button and drag it to another location, then release the right mouse button and paste various options such as move, copy as a block from the pop-up context menu.

GstarCAD Standard

Create shape definition

The new MKSHAPE command creates a shape definition based on the selected objects. Shapes are used to quickly display relatively simple geometry. The size of a shape is limited to 2200 bytes of data. If you create a shape that exceeds this limit, MKSHAPE creates complex geometric shapes to form a single shape.

GstarCAD Standard

Viewport scale

The new VPSCALE command returns the real scale of the current viewport of a selected layout viewport from the command line.

GstarCAD 2018

GstarCAD Standard

Section plane command

The SECTIONPLANE command creates a section plane through 3D objects and saves the selected section plane as a 2D or 3D block. You can move the section object dynamically in a 3D model / surface. You can use the active section to analyze a model by moving the section object through the object.

GstarCAD Standard

New arrangement options

Allows you to make copies of objects arranged in RECTANGULAR, POLAR, or PATH patterns. The new arrangement object is a whole (dynamic block). It can be dynamically adjusted by the number of objects, distance and other related parameters via ribbon panel and multifunctional handles.

GstarCAD Standard

DWG conversion

The DWGCONVERT command converts one or a batch of drawing files to an older or current DWG version. The newly created file can overwrite the original file and it can also be compressed into a self-extracting EXE file or a ZIP file to facilitate the batch format conversion of the entire project drawing.

GstarCAD Standard

Improved crop command

The new command CLIP cuts the selected objects such as blocks, external references, images, viewports and documents (PDF or DGN) to a specified boundary. It can be used to replace XCLIP, IMAGECLIP, VPCLIP, PDFCLIP, DGNCLIP commands.

GstarCAD Standard

Command hatching to the back

To avoid a fill pattern blocking text, labels or other graphics in the current drawing, you can move the display order of all fill patterns backwards with the HATCHTOBACK command.

GstarCAD Standard

Add selected

The ADDSELECTED command creates a new object of the same type and with the same general properties as a selected object, but with different geometric values.

GstarCAD Standard

MULTIPLE

The MULTIPLE command repeatedly executes a command without the need to press the Enter key or the spacebar.

GstarCAD Standard

Auto Layer

The AUTOLAYER command enables you to adapt and predefine the associated layer of the command in order to optimize the design process.

GstarCAD Standard

Command preview

Shows exactly how the objects will look like after use of TRIM, EXTEND, and HATCH commands.

GstarCAD Standard

Command line

Now you can use the RIBBONCLOSE and RIBBON commands to show / hide the ribbon. When you type a command in the Command window, a list of the appropriate commands and variables is displayed for easy recognition, selection, and auto-completion.

GstarCAD Standard

View the plot styles

The Page Setup Manager for Layout now supports the Show Plot Styles option. You can assign different plot style tables to each layout in your drawing. Plot styles offer a lot of flexibility because you can use them to override other object properties or to turn off overrides as needed.

GstarCAD Standard

Free scale

The FREESCALE command allows you to scale an object or a group of objects without restrictions using three methods: Non-Uniform, Rectangular, and Free. The following objects: line, circle, arc, ellipse, polyline and point can be freely scaled.

GstarCAD Standard

Geometric center

A new Geometric Center Snap option has been added to improve the snap centers of any type of polygonal object.

GstarCAD Standard

M2LVPORT

The M2LVPORT command creates a viewport in layout space by specifying an area in model space. And then he calculates the size of the viewport according to the set ratio and places the viewport in the layout area. You can quickly create and set a viewport of your drawing.

GstarCAD Standard

Attribute increment

The ATTINC command helps to specify the block attribute with incremental numbers and to change the attribute value of the attribute block according to the sort value.

GstarCAD Standard

Area table

The AREATABLE command automatically dimensions and calculates the area of a closed object and exports the result to a table in the drawing area.

GstarCAD Standard
